1. IMPORTANT: Fully extend arm assembly
11
to
ensure enough slack in cables.
2. Route your cables through the arm assembly
11
as
shown.
2
Manage Cables
Your TV should adjust easily when moved, then
stay in place. If your TV is too loose or too tight use
the hex key
15
for additional tightening of the
right and left tilt tension screws
T
.
1. Loosen
security
screw
13
.
3. Retighten
security
screw
13
.
2. Level TV.
13
TILT ADJUSTMENT
LEVEL ADJUSTMENT
TV Adjustments
1. Remove your TV (PAGE 9).
2. Open the cover plates, remove two screws
12
,
and loosen
screws at bottom of arm
S
to release arm assembly
11
.
3. Reposition the arm assembly
11
on the wall plate (STEP 3.1).
4. Reattach the two screws
12
(STEP 3.1), tigthen the screws at
the bottom of arm
S
, and close the cover plates.
5. Hang your TV onto the arm assembly
11
following STEP 3.2.
12
12
08
11
08
11
LATERAL SHIFT
REMOVING THE TV
15
HEAVY! You may need assistance with this step.
HEAVY! You may need assistance with this step.
CAUTION:Avoid potential injuries or property damage!
Do NOT adjust the arm position from center for concrete
applications. Arm
11
MUST remain centered in wall plate
08
for all concrete applications!
1 2 3 4
14
15
11
T
15
T
15
13
15
REMOVING THE ARM
1
2
11
08
12
15
15
15
13
08
Locking screw
13
MUST be installed to
secure the TV mount
and the arm assembly.
S
15
S
