9
12 in.
(30 cm)
24 in.
(61cm)
12 in.
(30 cm)
TIP:
TIP:
To calculate your precise wall plate location, check out
our HeightFinder at sanus.com [www.sanus.com/1172].
1
POSITION TEMPLATE
Solid Concrete or Concrete Block Installation
● Mount the wall plate
06
directly onto the concrete surface
● Minimum solid concrete thickness: 8 in. (20.3 cm)
● Minimum concrete block size: 8 x 8 x 16 in. (20.3 x 20.3 x 40.6 cm)
● FOR CONCRETE APPLICATIONS, arm assembly
09
must
remain centered in wall plate
06
. Keep this in mind when
selecting the wall plate location
2B
CAUTION: Avoid potential personal injury or property damage!
sanus.com
/1172
HeightFinder™
Visit
Never drill into the mortar between blocks.
CAUTION:
Never drill into the mortar between blocks.
2
DRILL
3X
2X
CAUTION:
All five lag bolts
07
MUST BE firmly tightened to prevent unwanted
movement of the wall plate
06
.
Ensure the wall plate is securely
fastened to the wall before continuing on to the next step.
CAUTION: Avoid potential personal injury or property damage!
5X
4
SECURELY TIGHTEN
3/8 in.
(10 mm)
3 in. (7.6 cm)
05
05
06
07
3X
2X
CAUTION: Avoid potential personal
injury or property damage!
Install lag bolts into the slots AS SHOWN.
Three
3
X
lag bolts
07
at the top.
Two
2
X
lag bolt
07
at the bottom.
#
2
#
3
#
4
#
5
#
6
#
2
#
7
#
6
#
1
#
3
#
5
#
7
#
4
(Center)
#
1
05
5X
CAUTION:
Be sure the anchors
08
are seated flush with
the concrete surface.
CAUTION:
33
INSERT ANCHORS
08
