Je bekijkt pagina 10 van 16
10
ATTACH TV TO WALL PLATE
STEP 3
3/32 in.
5/32 in.
10-32 x 3/8 in.
Parts and Hardware for STEP 3
Arm Assembly
LOCKING SCREWS
(ATTACHED)
10
09
Securement Screw
12
11
Hex Key
Hex Key
06
09
1
HANG
06
09
09
For CONCRETE APPLICATIONS:
The arm assembly
09
MUST remain centered in wall plate
06
.
CAUTION: Avoid potential personal injury or property damage!
HEAVY! You may need
assistance with this step.
2
SECURE
09
06
S
12
3
CLOSE COVERS
Always make sure both locking screws
S
are tightened, so the arm
assembly
09
is securely fastened to wall plate
06
.
CAUTION: Avoid potential personal injury or property damage!
P
P
S
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included
and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts!
3.1 Attach the Arm Assembly to the Wall Plate
(qty. 1)
(qty. 1)
(qty. 1)
(qty. 1)
06
