9
English
Installation Procedure
Step 1 Choosing the installation location
WARNING
• If appliances contain R-32 refrigerant, then the floor area of
the room in which the appliances are installed, operated and
stored must be larger than the minimum floor area defined
in table below A (m²).
Minimum required room area (A, m²)
m (kg) Ceiling-mount type
≤1.842 No requirement
1.843 3.64
1.9 3.75
2.0 3.95
2.2 4.34
2.4 4.74
2.6 5.13
2.8 5.53
3.0 5.92
3.2 6.48
3.4 7. 32
3.6 8.20
3.8 9.14
4.0 10.1
4.2 11.2
4.4 12.3
4.6 13.4
4.8 14.6
5.0 15.8
5.2 17.1
5.4 18.6
5.6 20.0
5.8 21.5
6.0 23.0
• m : Total refrigerant charge in the system
• A :
Minimum required room area
• IMPORTANT: it’s mandatory to consider either the table
1 or taking into consideration the local law regarding the
minimum living space of the premises.
• Minimum installation height of indoor unit is 2.2 m for
ceiling-mount type.
Installation location requirements
• The outdoor unit shall be installed in an open space that
is always ventilated.
• The local gas regulations shall be observed.
• For installation inside a building (this applies either to
indoor or outdoor units installed inside) a minimum room
floor area of space conditioned is mandatory according to
EN378-1:2017 (see the reference table into the indoor unit
installation manual).
• To handle, purge, and dispose the refrigerant, or break
into the refrigerant circuit, the worker should have a
certificate from an industry-accredited authority.
• Do not install the air conditioner in following areas.
– The place where there is mineral oil or arsenic acid.
Resin parts flame and the accessories may drop or
water may leak. The capacity of the heat exchanger
may reduce or the air conditioner may be out of order.
– The place where corrosive gas such as sulfurous
acid gas generates from the vent pipe or air outlet.
The copper pipe or connection pipe may corrode and
refrigerant may leak.
– The place where there is a machine that generates
electromagnetic waves. The air conditioner may not
operate normally due to control system.
– The place where there is a danger of existing
combustible gas, carbon fiber or flammable dust.
– The place where animals may urinate on the product.
Ammonia may be generated.
– The place where thinner or gasoline is handled. Gas
may leak and it may cause fire.
– The place where is close to heat sources
• Do not use the indoor unit for preservation of food
items, plants, equipment, and art works. This may cause
deterioration of their quality.
• Do not install the indoor unit if it has any drainage
problem.
• Do not place the outdoor unit on its side or upside down.
Failing to do so may cause the compressor lubrication
oil to run into the cooling circuit and lead to a serious
damage to the unit.
• Install the unit in a well-ventilated location away from
direct sunlight or strong winds.
• Install the unit in a location that would not obstruct any
passageways or thoroughfares.
• Install the unit in a location that would not inconvenience
or disturb your neighbors, as they could be affected by
the noise or the airflow coming from the unit.
