Installation Procedure
English
Installation Procedure
Step 2 Fixing the outdoor unit in place
Installtheoutdoorunitonarigidandstablebase
topreventdisturbancefromanynoisecausedby
vibration.Wheninstallingtheunitataheightorina
locationexposedtostrongwinds,fixtheunitsecurely
toasupport(i.e.,awalloraground).
Fixtheoutdoorunitwithanchorbolts.Makesurethat
theanchorboltsare20mmorhigherfromthebase
surface.
601.7
790
285
310
336
Anchor bolt hole
CAUTION
• Installadrainoutletatthelowestendaroundthe
baseforoutdoorunitdrainage
• Wheninstallingtheoutdoorunitontheroof,
waterprooftheunitandchecktheceilingstrength.
• Makesurethatthewallcansupporttheweightsof
therackandtheoutdoorunit.
• Installtherackclosetothecolumnasmuchas
possible.
Optional: Fixing the outdoor unit to a wall with
a rack
Soft rubber designed to cut off vibration from rack to wall.
(not supplied with product)
Designed to cut off residual vibration from outdoor unit to
rack. (not supplied with product)
Anchor bolt
Base surface
20 mm
• Installapropergrommetinordertoreducenoise
andresidualvibrationtransferredbytheoutdoor
unittowardsthewall.
CAUTION
• Wheninstallinganairguideduct,besuretocheck
thefollowing:
– Thescrewsdonotdamagethecopperpipe.
– Theairguideductisfixedfirmlyontheguard
fan.
