Installation Procedure
When installing more than 1 outdoor unit
(Unit: mm)
1500
or more
600
or more
3000
or more
3000
or more
300
or more
600
or more
600
or more
1500
or more
300
or more
1500
or more
600
or more
600
or more
300
or more
600
or more
600
or more
600
or more
300
or more
300 or more
300 or more
500 or more 500 or more
CAUTION
• Theoutdoorunitmustbeinstalledaccording
tothespecifieddistancesinordertopermit
accessibilityfromeachside,toguaranteecorrect
operation,maintenance,andrepairoftheunit.The
componentsoftheoutdoorunitmustbereachable
andremovableundersafeconditionsforpeople
andtheunit.
WARNING
• Shouldadoptbartypelouver.Don’tuseatypeof
rainresistancelouver.
[Bar type louver] [Rain resistance louver]
• Louverspecifications.
– Anglecriteria:lessthan20°
– Openingratiocriteria:greaterthan80%
Moving the outdoor unit with wire rope
1 Beforecarryingtheoutdoorunit,fastentwowire
ropesof8morlonger,asshowninthefigure.
2 Topreventdamagesorscratcheseffectively,insert
apieceofclothbetweentheoutdoorunitandthe
ropes.
3 Movetheoutdoorunit.
Wire rope
Plate protection cloth
• Theappearanceoftheunitmaybedifferentfrom
thepicturedependingonthemodel.
