CHAPTER 1
Introduction
Description
The PS-20 is a complete and independent power supply, with the added features of 2- and 4-channel operation, monitoring, 2-
channel program input, audio linking and three (3) modes of operation: RTS 2-channel, RTS 4-channel and
Clear-Com
mode.
The PS-20 features two (2) channels of communication where both channels are wet, meaning there is power on each channel
(RTS 2-channel mode). In RTS 4-channel mode, the audio signals and DC exist on the same wire, unlike in Clear Com mode,
where the audio and power are on separate lines. Where the PS-15 has power on CH 1 only, power is on both CH 1 and CH 2
on the PS-20.
The PS-20 has a 3-pin XLR (male) connector on the front of the system, where a user can connect to the power supply and
monitor activity on CH 1 or CH 2 (see Figure 1 on page 9). In Clear-Com mode, only channel one (1) is heard. A user station
or beltpack is required to use a headset with this feature.
A single PS-20 Power Supply can power up to 50 user stations (depending on the model and combination - see specifications).
If still more user stations or beltpacks are needed, two PS-20 Power Supplies can be joined together to double the power
capability.
A pair of standard stereo plug connectors are available on the back of the power supply to connect two (2) PS-20 power
supplies through audio linking.
The PGM IN (3-pin XLR female) connector can be used to send Audio to CH 1 and/or CH 2 (for example, a radio station users
can listen to while they work).
Features
Selectable Mode
Operation -
The PS-20 is selectable between RTS 2-channel, RTS 4-channel and Clear-Com mode.
Audio Linking - Audio Linking allows you to connect up to two (2) PS-20s with a standard stereo cable. There
is an Audio Link for CH1 and CH2 and an Audio Link for CH3 and CH4 connection for two
way communications. To learn how to configure Audio Linking, Figure 2, “Audio Linking
Two-way communication configuration.,” on page 12
Monitoring - The 3-pin XLR Monitoring Output connector allows the user to monitor a channel or
channels. A user station or beltpack is required to use a headset with this feature.
NOTE: In Clear-Com mode, only channel one (1) is heard.
