KP Series Basic Operation 41
Keypad Reference View
With both the KP-4016/4016PB and KP-5032/5032PB, there are three tiers of operation for a keypanel’s keypad: Primary
Mode, SHIFT Mode, and Dial Mode.
Primary Mode
Primary Mode is used for the most common keypanel functions, such as CLR, SEL, and accessing the Main menu. There are
no special keypad sequences to use these functions.
Dial Mode
DIAL Mode is used to complete telephone operations. For more information, see “Telephone Interface (TIF) Operation” on
page 259. When the keypanel is in DIAL mode, the keypad keys support the standard telephone DTMF keypad configuration
as a third tier function. The DTMF keypad is seen in the upper-left corner of the keypad keys.
SHIFT Mode
SHIFT Mode contains secondary functions used to access more utilities on the keypanel. The SHIFT mode functions are
located on the primary keypad keys. The shift functions available are COPY, DIAL, DROP, LEFT, RIGHT, LSTN, VM, INFO,
UPG2 AFK, and TYPE.
NOTE: By default, the keypad backlight changes to white when the keypad is in SHIFT mode. For more information, see
“Service Menu, Keypad” on page 243.
To access SHIFT Mode, do the following:
1. On the keypad, press the SHIFT button.
2. On the keypad, press the SHIFT mode button desired.
NOTE: Once SHIFT mode is entered, exit the mode by pressing the SHIFT key again, without pressing any other
keys.
KP-5032PB KP-4016PB
FIGURE 9. KP-5032, KP-5032PB, KP-4016, and KP-4016PB Keypad
