45
Changing the Output Source of the Second Connectors
On the V-1600HD, you can assign PGM, PVW or AUX output to the output connectors described below. You can assign the output
sources independently to each respective output connector.
• SDI OUT (2)
• DVI-D/HDMI OUT (2)
• RGB/COMPONENT OUT
• SD OUT (COMPOSITE/S-VIDEO)
fig.assigneble-outs.eps
* By default, AUX output is assigned to these connectors.
* Only the PGM can be assigned to the SDI OUT (1:PGM) or DVI-D/HDMI OUT (1:PGM) connector.
Viewing the List of Source Assignments
You can view a list showing which sources are assigned to which connectors. Press the [OUTPUT] button to make the output-
related menu appear. It displays the assignments to the respective connectors and the output formats, as shown below.
fig.source-assign.eps
PGM PVW AUX
PGM PVW AUX PGM PVW AUX PGM PVW AUX
