12
Making the Pad Settings
Selecting from the TMC-6’s panel (Trigger Chase OFF)
1. Press the [EDIT] button to make its indicator light.
This takes you into Edit mode.
2. If the [TRIGGER SELECT] button is not lit, it indicates that Trigger
Chase is OFF.
If the button is lit, hold down the button until the light goes out.
3. Press the [TRIGGER SELECT] button to select the trigger input to be
set.
Each press of the button takes you to the next selection for the trigger,
allowing you to cycle through the available choices, which might be: “Input
1 Head,” “Input 1 Rim,” “Input 2 Head,” “Input 2 Rim,” and so forth. (The
trigger inputs that can be selected may vary depending on the selected
parameter; refer to the table below). Take care not to mistake trigger input
selections when connecting pads with separate head and rim settings (the
HEAD/RIM indicator is lit when the rim is selected).
o: Can be selected -: Cannot be selected
*1: You can choose this only when the Hi-Hat control pedal is pressed. (Be
sure that the TRIG 6/HH CTRL switch is set to HH CTRL.)
*2:
You can choose this only when the TRIG 6/HH CTRL switch is set to TRIG 6.
■ Specifying a Trigger Type
4. Rotate the parameter select knob to “TRIG TYPE.”
5. Set the value using the [INC/+] and [DEC/-] buttons.
Selected
Parameter
Trigger Select
1 2 3 4 5 5 6
Head Rim Head Rim Head Rim Head Rim Head
(Open)
Head
(Close)
*1
Rim
(Open)
Rim
(Close)
*1
Head
(HH
CTRL)
Rim
*2
MIDI CHANNEL–
MIDI NOTE No.
o o o o o o o o o o o o o o
THRESHOLD–
XTALK CANCEL
o - o o o - o - o - - - o -
TRIG TYPE (Trigger Type) refers to a group of complex trigger parameters
that are set to the proper values for each different type of pad. Selecting the
Trigger Type corresponding to the connected pad sets each of the pad
parameters to the most appropriate values, thus allowing you to perform
immediately without problems in most cases. If you find you are unable to
perform well using, for example, an acoustic drum trigger, then you will need
to select the Trigger Type, and then proceed with fine adjustments to
individual parameters to obtain the proper settings for the pad you are using.
A text description of the
“TRIG TYPE” that is
shown in the display also
appears in the bottom of
the TMC-6.
For more detailed
information on all
parameters, refer to the
"Parameter List" (p. 24).
