MFX parameter list
Parameter Value Explanation
Rate (Hz) 0.05–10.00 [Hz] Frequency of modulation
Rate (note) 1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Depth 0–127 Depth at which the wah eect is
modulated
Phase 0–180 [deg] Adjusts the degree of phase shift of
the left and right sounds when the
wah eect is applied.
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Level 0–127 Output Level
Humanizer
Adds a vowel character to the sound, making it similar to a human voice.
L in
R in
L out
R out
Pan L
Pan R
FormantOverdrive 2-Band EQ
Parameter Value Explanation
Drive Sw OFF, ON Overdrive on/o
Drive 0–127 Degree of distortion
Also changes the volume.
Vowel1 a, e, i, o, u Vowel 1
Vowel2 a, e, i, o, u Vowel 2
Rate (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Parameter Value Explanation
Rate (Hz) 0.05–10.00 [Hz] Frequency at which the two vowels
switch
Rate (note) 1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Depth 0–127 Eect depth
Input Sync
Sw
OFF, ON LFO reset on/o
Determines whether the LFO for
switching the vowels is reset by the
input signal (ON) or not (OFF).
Input Sync
Threshold
0–127 Volume level at which reset is
applied
Manual 0–100 Point at which Vowel 1/2 switch
0–49: Vowel 1 will have a longer
duration.
50: Vowel 1 and 2 will be of equal
duration.
51–100: Vowel 2 will have a longer
duration.
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Pan L64–63R Stereo location of the output sound
Level 0–127 Output Level
PHASER
Phaser
This is a stereo phaser. The phase of the original sound is shifted to
modulate the overall sound.
R outR in
L in L out
Mix
Mix
2-Band EQPhaser
Phaser 2-Band EQ
Parameter Value Explanation
Mode 4-STAGE,
8-STAGE,
12-STAGE
Number of stages in the phaser
Manual 0–127 Adjusts the basic frequency from
which the sound will be modulated.
Rate (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Rate (Hz) 0.05–10.00 [Hz] Frequency of modulation
Rate (note) 1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Depth 0–127 Depth of modulation
Polarity INVERSE,
SYNCHRO
Selects whether the left and right
phase of the modulation will be the
same or the opposite.
INVERSE: The left and right phase
will be opposite.
When using a mono source, this
spreads the sound.
SYNCHRO: The left and right phase
will be the same.
Select this when inputting a stereo
source.
Resonance 0–127 Amount of feedback
