5
Installation Instructions
Electrical Connection
Supply connection: 30A (double pole switched fused outlet with minimum 3mm contact gap)
Before connecting the appliance, ensure that the supply voltage marked on the data label corresponds with your
mains supply voltage.
WARNING: This appliance must be earthed.
Ensure that the power supply cable does not exceed a temperature of 50°C.
If the power supply cable is damaged, it must be replaced with an identical one which can be obtained from
customer service. The power supply must be replaced by a qualified and authorized person.
Warning: This appliance must be installed by a qualified electrician or authorized service provider.
Remember to connect the safety circuit to the connection box terminal marked with .The electricity supply for the
ceramic hob must have a safety switch which enables the power to be cut off in case of emergency. The distance
between the working contacts of the safety switch must be at least 3mm.
• The cable connections must be in accordance with the diagram located on the bottom of the hob.
• The cable type must be connected to the corresponding power supply terminal box.
• You should use a good quality screwdriver to carefully, fully tighten ALL of the terminal screws.
• If, when the hob is first switched on, only two of the zones work you should recheck that the terminal
screws are all fully tightened. This should be done before contacting the Customer Care Department.
• IMPORTANT: The appliance must NOT be connected to the mains supply by means of a 13A plug and
socket.
• This appliance must be wired into a 30A double pole switched fused spur outlet, having 3 mm contact
separation and placed in an easily accessible position adjacent to the appliance. It should not be located
above the appliance and no more than 1.25m away from it.
• The cable can be looped, if necessary, but make sure that is not kinked or trapped when the hob is in
position. Care must be taken to avoid the cable being in contact with hot parts of the appliance.
