4

Installation Instructions

Installing the Cooktop

Note: Before proceeding with installation read the work instructions carefully.

1. Place a towel or cloth on the work surface. Place the cooktop face down on

the protected surface.

2. Apply the strip seal, supplied with the hob, which is for sealing it onto the

work surface. Do not use silicone. Apply the seal to the edge of the bottom of

the cooktop, leaving about 3mm from the edge of the glass. Apply the seal all

around the circumference. Cut off any excess and bring the two ends of the

seal together so they match.

3. Fix the brackets (4 or 5 pcs) on the front side and rear side by screw. Put the

cooktop in the cut-out and make it centered. Ensure that the front edge of

the cooktop is parallel to the side edge of the work surface.

• IMPORTANT: You must observe the ventilation requirements shown in the figure below.

• IMPORTANT: There are ventilation holes around the outside of the cooktop. YOU MUST ensure that these

holes are not blocked by the benchtop when you put the cooktop into position (see figure below).

• IMPORTANT: Do not use a silicon sealant to seal the appliance against the benchtop. This will make it

difficult to remove the cooktop from the benchtop in the future, particularly if it needs to be serviced.
