Displays the measurement waveform window of analog and digital channels. Click
or tap at the upper-right corner of the window to close the window. Click or
tap to enter the configuration menu of the specified function.
2. Operating Status
Displays the operating status of the instrument.
3. Horizontal Timebase Label
Displays the current horizontal time base. Click or tap this label to enter the
horizontal setting menu.
4. Sample Rate & Memory Depth Label
Displays the current sample rate and memory depth. Click or tap this label to enter
the horizontal setting menu.
5. Horizontal Position Label
Displays the current horizontal position. Click or tap this label to enter the
horizontal setting menu.
6. Trigger Information Label
- Displays the trigger information of the system, including the trigger type,
trigger level, trigger mode, and etc.
- Click or tap the trigger information label, then the trigger setting window is
displayed. You can set the parameters for the trigger.
7. Quick Operation Toolbar
Provides STOP/RUN,
XY, Default, Flex Knob, Navigate keys and some function
keys in the function navigation menu for quick operation.
8. Result List
Displays the measurement results and statistics of various functions. Click or tap
at the lower-right corner of the screen to fold the "Result" list of the specified
function.
9. Notification Area
Displays the USB storage device icon, LAN connection icon, sound icon, and
remote control icon as well as date and time. You can click or tap this area to open
the "Utility" menu.
- USB storage device icon: When a USB storage device is detected,
will be
displayed.
- LAN connection icon: When the LAN interface is successfully connected, is
displayed.
Quick Start
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
31
