- Sound icon: In the "Utility" menu, click or tap Setup > Beeper to enable or
disable the sound. When enabled, will be displayed; when disabled, will
be displayed. You can also click on or tap the icon to enable or disable the
sound.
- Remote control icon: When you control use Web Control to control the
instrument remotely, will be displayed.
- Date and time: Displays the system date and time. You can set them in the
Setup menu.
10. Channel Operation Label
Displays the on/off state, operation type, and vertical scale of Math1-Math4.
11. Digital Channel Label
Displays the current on/off status of the 16 digital channels. When a digital
channel is enabled, click or tap this label to enter the logic analyzer (LA) setting
menu.
12. Function/Arbitrary Waveform Generator Label
[1]
Displays the on/off state, waveform type, amplitude, and frequency for Arbitrary
Waveform Generator GI/GII. Click or tap the label to enable/disable the AFG
output. When the AFG output is enabled, click or tap this label to open the AFG
setting menu.
13. Multi-pane Windowing Display Area
If you enable multiple functions, multiple windows can be displayed on the screen
at one time.
14. Analog Channel Label
- Displays the on/off status of analog channels (CH1-CH4).
- Displays the channel coupling mode.
- Displays the vertical scale of the channel.
- Displays the vertical offset of the channel.
15. Function Navigation Icon
Click or tap the icon to open the function navigation menu. Click or tap the
specified menu icon to enter the specified function setting menu.
NOTE
[1] : Available to use when the MHO2000-AWG option has been installed.
Quick Start
MHO2000 User Guide
32
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
