24
To Store and Load
You can save the current setups, waveforms, screen image, and parameters of the
oscilloscope to the internal memory or external USB storage device (such as USB
storage device) in various formats and recall the stored setups or waveforms when
necessary. You can also load the upgrade software to the system and perform the
upgrade operation for the instrument.
You can also copy, delete, or rename the specified type of file from the internal
memory or external USB storage device via the disk management menu.
This oscilloscope provides two USB HOST interfaces on the front panel, which can all
be connected to the USB storage device for external storage. The USB storage devices
connected are marked as "Removable USB Disk (D)" and "Removable USB Disk (E)".
TIP
This oscilloscope only supports the flash memory USB storage device of FAT32 format.
24.1 To Enter the Storage Menu
You can enter the storage setting menu in the following ways.
• Click or tap the function navigation icon at the lower-left corner of the
screen, and then select Storage to enter the storage setting menu.
• Click or tap the Storage button on the toolbar to enter the storage setting
menu.
In the
Storage setting menu, there are three sub-menus (Save, Load, and Upgrade)
for you to choose. Select the specified sub-menu and configure the corresponding
parameters.
24.2 To Save a File
In the Storage interface, click or tap the Save tab to enter the file saving menu.
To Store and Load
MHO2000 User Guide
270
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
