Window Transparency
In the Display setting menu, drag the slide bar of Window Transparency to set the
window transparency. The default is 50%, and the range available is from 0% to 100%.
Cursor Brightness
In the Display setting menu, drag the slide bar of Cursor Brightness to set the cursor
brightness. The default is 80%, and the range available is from 0% to 100%.
23.6 Show Scale
In the Display setting menu, click or tap the ON/OFF tab for Show Scale to enable or
disable the scale display on the screen. By default, it is ON.
23.7 Color Grade
In the Display setting menu, click or tap the ON/OFF tab for Color Grade to enable
or disable the color grade. By default, it is OFF.
When enabled, different colors are displayed on the screen to indicate the times of
data acquisition or acquisition probability.
23.8 Waveform Freeze
In the Display setting menu, click or tap the ON/OFF tab for Waveform Freeze to
enable or disable the waveform freeze function. By default, it is ON.
When enabled, the oscilloscope displays the waveform that has undergone multiple
samplings and superpositions after sampling is stopped when you click or tap the
STOP/RUN icon on the quick operation toolbar or press on the front panel. If
disabled, the last triggered waveform is displayed.
Display Control
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
269
