• Both: samples the channel data on the rising edge or the falling edge of the
clock.
19.1.2 Bus Setting
Set the Bus
You can select the analog channel or the digital channel as the bus source. You can
also use the user-define bus source.
Table 19.1 Bus Setting
Bus Width Bit X Channel Remarks
CH1 1 0 CH1
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
CH2 1 0 CH2
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
CH3 1 0 CH3
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
CH4 1 0 CH4
Width, Bit X, and CH are set
automatically, and you cannot
modify them.
D7-D0 8 0 (default) D0 (default)
Bit0 to Bit7 are set to D7 to
D0 respectively. Width is set
automatically, and you cannot
modify it.
D15-
D8
8 0 (default) D8 (default)
Bit0 to Bit7 are set to D15 to
D8 respectively. Width is set
automatically, and you cannot
modify it.
D15-
D0
16 0 (default) D0 (default)
Bit0 to Bit15 are set to D15 to
D0 respectively. Width is set
automatically, and you cannot
modify it.
Protocol Decoding
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
221
