18.2 To Select the Source
Click or tap the drop-down button of Source to select the desired source from the
drop-down list. The available channels include CH1-CH4.
TIP
When the disabled channel is selected as the source, it will be enabled automatically.
18.3 To Set the Test Mask
In the Pass/Fail menu, you can self-define the pass/fail test mask, save and load the
test mask.
Create a Mask
Click or tap the input field of X Mask and Y Mask respectively to set the horizontal
tolerance range and vertical tolerance range with the pop-up numeric keypad. You
can also use the Up/Down arrow at the right side of the input field of
Y Mask to
adjust the value of Y Mask; use the Left/Right arrow at the right side of the input field
of
X Mask to adjust the value of X Mask. Also, you can use the specified knob
indicated in the input field of Y Mask and X Mask to set it respectively. After
configuring the settings, click or tap Create to apply the currently created mask (the
region not covered by blue within the screen).
Load a Mask
When the pass/fail test function is enabled, you can load the test mask files from the
internal memory or external USB storage device (when detected) and apply them to
the current pass/fail test function.
Click or tap
Load to enter the file loading interface. Click or tap the input field of File
Path to load the specified test mask files (in *.pf format) and apply them to the
current pass/fail test function. For detailed operations, refer to descriptions of
Disk
Management
in
To Store and Load
.
Save a Mask
When the pass/fail test function is enabled, you can save the current test mask range
to the internal memory or external USB storage device (when detected) in "*.pf"
format.
Click or tap
Save to enter the file saving interface. Click or tap the input field of File
Name and File Path to input the filename and select the desired file path to save the
test mask file to the internal or external memory. For detailed operations, refer to
descriptions of
Disk Management
in
To Store and Load
.
Pass/Fail Test
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
215
