Select the Ref Source
Click or tap the drop-down button of Source to select the desired source of the
reference waveform. The available sources include analog channels, digital channels,
and Math1-Math4.
Save the Reference Waveform to Internal Memory
Click or tap
SaveToRef to save the displayed waveform for the specified source to the
internal memory as the reference waveform.
CAUTION
This operation only saves the reference waveform to the volatile memory, and the
waveform will be cleared at power-off or restoring to the default settings. If you want to
store reference waveforms that can be recalled when necessary, please export the
waveform to internal or external memory (
Export to Internal or External Memory
).
Clear the Specified Reference Waveform
Click or tap
Clear to clear the specified reference waveform for the "current
channel".
You can also click or tap the Clear icon in the function navigation menu to clear the
reference waveforms of all the reference channels. Also, you can press the front-panel
key to clear the reference waveforms of all the reference channels.
Minimize the Reference Waveform Window
Click or tap the ON/OFF tab for
Minimize to select whether to minimize the reference
waveform setting window. By default, it is OFF.
When enabled, the reference waveform setting window will be minimized to be
displayed at the right section of the screen. You can set the parameters in the
minimized window. To restore to the normal display of the window, click or tap
Max.
To close the window, click or tap
Close.
17.3 To Set the Ref Waveform Display
After clicking or tapping SaveToRef to save the current channel as reference
waveform channel, you can adjust the vertical scale, vertical offset, and horizontal
offset of the reference waveform specified under Current.
Adjust the Vertical Scale
Click or tap the input field of VScale to input the vertical scale of the reference
waveform with the pop-up numeric keypad. You can also click or tap the icon
at the right of the input field of VScale to increase or decrease the vertical scale. Also,
Reference Waveform
MHO2000 User Guide
210
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
