• Click or tap the drop-down button of Freq.Ref to select "Voltage" or "Current" as
the frequency reference.
Set the Reference Level
• Click or tap the drop-down button of Type to set the reference level display type
to "Percent(%)" or "Absolute".
• Click or tap the input field of Upper to set the upper limit value with the pop-up
numeric keypad. You can also use the specified multifunction knob to set the
value. The upper limit value should be greater than the middle value.
• Click or tap the input field of
Mid to set the middle value with the pop-up
numeric keypad. You can also use the specified multifunction knob to set the
value. The middle value should be smaller than the upper limit value and greater
than the lower limit value.
• Click or tap the input field of
Lower to set the lower limit value with the pop-up
numeric keypad. You can also use the specified multifunction knob to set the
value. The lower limit value should be smaller than the middle value.
• Click or tap
Default, and then the upper value, middle value, and lower value will
be restored to the defaults.
Set the Count
Click or tap the input field of
Count to set the statistical count of the power quality
analysis with the pop-up virtual numeric keypad. You can also use the specified knob
indicated in the input field to set it. Its range is from 1 to 1,000. By default, it is 500.
Click or tap
Reset Stat. to clear the current data and execute statistics on the
measurement results again.
Enable the Power Analysis
Click or tap the ON/OFF tab for
Enable to enable or disable the power quality
analysis. When enabled, the statistical results will be displayed on the screen. Click or
tap the close icon
at the upper-right corner of the power analysis result interface
to close the window.
Power Analysis (Option)
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
205
