The input source indicates the channel input with the reference signal. The
current frequency takes the frequency of this channel as the reference. The
analog channel can be selected as the input source. The default input channel is
CH1. Before selecting the input source, connect the signal under test to the
analog channel input terminal of the oscilloscope.
• Output Source:
The output source indicates the channel that connects the feedback output
signal. The analog channel can be selected as the output source. The default
output channel is CH2. Before selecting the output source, connect the signal
under test to the analog channel output terminal of the oscilloscope.
15.1.4 To Set the Sweep Signal
Sweep Source
Selects the AFG channel from the drop-down list of AFG Chan as the channel source
to output the sweep signal. The default channel is AFG1.
Sweep Type
Click or tap the drop-down button of Sweep Type to select "Log" or "Linear".
• Linear: the frequency of the swept sine wave varies linearly with the time.
• Log: the frequency of the swept sine wave varies logarithmically with the time.
15.1.5 To Set the Display Type
Click or tap the drop-down button of Disp Type to select "Wave" or "Chart".
Waveform Display
The Bode plot waveform display is as shown in the figure below. The X-axis in the
Bode plot represents the frequency; and the Y-axis represents gain or phase. The
magnitude-frequency curve (indicated in red) represents the gain between system
input and output. The phase-frequency curve (indicated in green) represents the
phase deviation between system input and output.
Bode Plot
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
199
