NOTE
The Bode plot function can only test the response of basic devices such as amplifiers, but
cannot test circuits with greater noises.
15.1 Basic Setting
Click or tap the Basic Setting tab to enter the basic setting menu. In this menu, you
can enable or disable the Bode plot function, start or stop the Bode plot operation,
set the input/output source, set the sweep type and display type, and check the
connection diagram.
In the Bode Plots setting menu, click or tap the ON/OFF tab for Bode Plot to enable
or disable the Bode function. After the Bode plot function is enabled, the Bode plot
window will be displayed on the screen.
15.1.1 To Enable or Disable the Bode Plot Function
In the Bode plot setting interface, click or tap the ON/OFF tab for Bode Plot to
enable or disable the Bode plot function. After the Bode plot function is enabled, the
Bode plot window will be displayed on the screen. For the Bode plot display interface,
refer to
To Set the Display Type
.
15.1.2 To Run or Stop the Drawing of the Bode Plot
When the Bode plot is enabled, in the Bode plot interface, click or tap
for Operating Status to start the loop analysis and Bode plot drawing based on the
current Bode plot settings. In the running status, is displayed for
Operating Status. After completing the Bode plot drawing, the icon after the
Operating Status menu turns out to be .
To stop Bode plot drawing during the drawing process, click or tap
to
suspend drawing.
NOTE
After completing the Bode plot test, the Bode plot setting interface is closed automatically. To
open the Bode plot setting interface again, click or tap at the upper-right corner of the
Bode plot window.
15.1.3 To Set the Input/Output Source
• Input Source:
Bode Plot
MHO2000 User Guide
198
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
