Select the Modulation Type
Click or tap the drop-down button of Mod. Type to select "PM".
Select the Modulating Waveform
The instrument uses the built-in signal to perform waveform modulation. Click or tap
the drop-down button of Waveform to select the modulating waveform. The
available waveform types include:
•
Sine
• Square with 50% duty cycle
• Triangle with 50% symmetry
• UpRamp with 100% symmetry
• DnRamp with 0% symmetry
• Noise - white gaussian noise
To Set the Phase Deviation
The phase deviation represents the peak variation in phase of the modulated
waveform from the carrier waveform. Click or tap the input field of
Phase Dev to set
the phase deviation with the pop-up numeric keypad. You can also use the specified
knob indicated in the input field to set it. The available setting range of the phase
deviation is from 0° to 360°. By default, it is 90°.
Set the Modulation Frequency
When you select the modulating waveforms other than Noise, you can set the
modulation frequency. Click or tap the input field of
Mod. Freq to set the modulation
frequency with the pop-up numeric keypad. You can also use the specified knob
indicated in the input field to set it. The available range of the PM frequency is from 2
mHz to 1 MHz.
Enable the Modulation Output
Click or tap ON for
Mod. State to enable the modulation function. In the Basic
Waveforms interface, click or tap ON for
Output to enable the waveform output.
Then the modulated waveforms will be output from the specified AFG terminal based
on the settings.
Function/Arbitrary Waveform Generator (Option)
MHO2000 User Guide
196
