• UpRamp with 100% symmetry
• DnRamp with 0% symmetry
• Noise - white gaussian noise
Set the Modulation Depth
Modulation depth is a percentage that represents the amplitude variation. Click or tap
the input field of Mod. Depth to set the modulation depth with the pop-up numeric
keypad. You can also use the specified knob indicated in the input field to set it. The
available range of the modulation depth is from 0% to 120%. By default, it is 100%.
• At 0% depth, the output amplitude is half of the carrier waveform amplitude.
• At 100% depth, the amplitude is identical to the carrier's amplitude setting.
• At >100% depth, the output amplitude of the instrument will not exceed 10 Vpp.
Set the Modulation Frequency
When you select the modulating waveforms other than Noise, you can set the
modulation frequency. Click or tap the input field of
Mod. Freq to set the modulation
frequency with the pop-up numeric keypad. You can also use the specified knob
indicated in the input field to set it. The available range of the AM frequency is from 2
mHz to 1 MHz.
Enable the Modulation Output
Click or tap ON for
Mod. State to enable the modulation function. In the Basic
Waveforms interface, click or tap ON for
Output to enable the waveform output.
Then the modulated waveforms will be output from the specified AFG terminal based
on the settings.
DSSC
Click or tap ON for
DSSC to enable the DSSC function. It can remove the carrier
components from the output signal, improve the bandwidth usage, and improve the
efficiency of transmission power.
14.2.2 FM
FM (Frequency Modulation), namely the frequency of the carrier waveform changes
with the voltage of the modulating waveform.
