You can also click or tap to switch to the HighL and LowL tab to set the high level
and low level of the Noise waveform. For details, refer to descriptions in
Sine
.
14.1.6 DC
In the Basic Waveforms tab, click or tap the drop-down button of Type to select "DC".
Then you can set the DC parameters.
Click or tap the input field of Offset to set the offset of the DC signal with the pop-up
numeric keypad. You can also use the specified knob indicated in the input field to set
it. The available range of offset is from -10 V to 10 V.
14.1.7 Exp.Rise
The Exp.Rise waveform is as shown in the figure below
Figure 14.2 Exp.Rise
In the Basic Waveforms tab, click or tap the drop-down button of Type to select
"Exp.Rise". Then set the Exp.Rise parameters. For setting methods, refer to
descriptions in
Sine
.
14.1.8 Exp.Fall
The Exp.Fall waveform is as shown in the figure below.
Function/Arbitrary Waveform Generator (Option)
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
187
