Figure 14.3 Exp.Fall
In the Basic Waveforms tab, click or tap the drop-down button of Type to select
"Exp.Fall". Then set the Exp.Fall parameters. For setting methods, refer to descriptions
in
Sine
.
14.1.9 ECG1
The ECG1 waveform is as shown in the figure below
Figure 14.4 ECG1
In the Basic Waveforms tab, click or tap the drop-down button of
Type to select
"ECG1". Then set the ECG1 parameters. For setting methods, refer to descriptions in
Sine
.
14.1.10 Gauss
The Gauss waveform is as shown in the figure below:
Function/Arbitrary Waveform Generator (Option)
MHO2000 User Guide
188
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
