• Sine: 1 μHz to 50 MHz
• Square/Pulse: 1 μHz to 30 MHz
• Ramp: 1 μHz to 2 MHz
• DC and Noise: no frequency parameter.
Set the Amplitude
Click or tap the input field of Amp to set the amplitude of the current Sine signal with
the pop-up numeric keypad. You can also use the specified knob indicated in the
input field to set it. The amplitude range of the Sine waveform is as follows:
• 2 mVpp to 10 Vpp (1 MΩ)
• 1 mVpp to 5 Vpp (50 Ω)
Set the Offset
Click or tap the input field of
Offset to set the offset of the current Sine signal with
the pop-up numeric keypad. You can also use the specified knob indicated in the
input field to set it. The offset range is from 1 nV to 1 µV.
• -9 V to 9 V (1 MΩ)
• -4.5 V to 4.5 V (50 Ω)
Set the High/Low Level
In the amplitude and offset setting of the output waveform, you can also click or tap
to select
HighL or LowL to set the high level and low level of the output waveforms.
• Amplitude = (High Level - Low Level)/2
• Offset = (High Level + Low Level)/2
The available range of high level is from -2.5 V to +10 V. By default, it is 1 V. The
available range of low level is from -10 V to +2.5 V. By default, it is -1 V.
Set the Start Phase
Click or tap the input field of
Phase to set the start phase with the pop-up numeric
keypad. You can also use the specified knob indicated in the input field to set it. The
available range of start phase is from 0° to 360°. By default, it is 0°.
Align Phase
Click or tap
Align Phase to re-configure the two channels to output according to the
set frequency and phase. If these two signals whose frequencies are identical or in
multiple, you can click or tap this menu to align their phases.
Use the oscilloscope to acquire the waveforms of the two channels and stably display
the waveforms. After switching the channel status, the phase deviation between the
Function/Arbitrary Waveform Generator (Option)
MHO2000 User Guide
184
