Measurement Histogram
When completing the measurement of specified parameters, you can view the data
distribution of measurement results through the measurement histogram function.
Click or tap the ON/OFF tab for Histogram to enable (ON) or disable (OFF) the
measurement histogram function.
When the measurement histogram function is enabled, the histogram waveform is
displayed in the measurement histogram window. The measurement histogram result
is displayed in the result list. The measurement results includes the following items:
• Type: indicates the measurement item.
• Sum: indicates the sum of all bins (buckets) in the histogram.
• Peaks: indicates the maximum number of hits in any single bin.
• Max: indicates the value that corresponds to the maximum bin that has any hits.
• Min: indicates the value that corresponds to the minimum bin that has any hits.
• Pk_Pk: indicates the Delta between the max. value and the min. value.
• Mean: indicates the average value of the histogram.
• Median: indicates the median value of the histogram.
• Mode: indicates the mode value of the histogram.
• Bin width: indicates the width of each bin (bucket) in the histogram.
• Sigma: indicates the standard deviation of the histogram.
• XScale: indicates the horizontal scale of the histogram. It is 100 times the value
of Bin width.
Indicator
Click or tap
ON or OFF for Indicator to enable or disable the indicator.
If enabled, one or multiple cursors will be displayed on the screen. Before enabling
the indicator, you need to at least enable one auto measurement parameter and the
number of cursors will change with the measurement parameter enabled.
TIP
No cursor will be displayed if no cursor measurement parameter is selected or the
measurement source has no input. When the waveform is expanded or compressed
horizontally, the cursor will move accordingly.
Measurements
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
153
