Source
Click or tap the drop-down button of SourceA or SourceB to select CH1~CH4 or
Ref1~Ref10. When a source channel is selected, the selected channel automatically
switches to the ON state.
TIP
In addition to CH1~CH4 and Ref1~Ref10, the available sources for Math2 also include Math1;
the sources for Math3 also include Math1 and Math2; the sources for Math4 also include
Math1, Math2, and Math3. The selected Math channel and operation status will automatically
be enabled.
9.2 Function Operation
In the Math menu, click or tap the drop-down button of Operator to select the
desired function operation. The available function operation types of this oscilloscope
include Intg, Diff, Sqrt, Lg (Base 10 Exponential), Ln, Exp, Abs, and AX+B.
• Intg: calculates the integral of the selected source. For example, you can use
integral to measure the area under a waveform or the pulse energy.
• Diff: calculates the discrete time derivative of the selected source. For example,
you can use differentiate to measure the instantaneous slope of a waveform.
• Sqrt: calculates the square roots of the selected source point by point and
displays the results.
• Lg (Base 10 Exponential): calculates the base 10 exponential of the selected
source point by point and displays the results.
• Ln: calculates the natural logarithm (Ln) of the selected source point by point
and displays the results.
• Exp: calculates the exponential of the selected source point by point and
displays the results.
• Abs: calculates the absolute value of the selected source and displays the results.
• AX+B: applies a linear function to the selected source, and displays the results.
Math Operation
