Je bekijkt pagina 144 van 332
displayed. You can set the upper limit and lower limit of the data word. For
details, refer to descriptions in
I2C Trigger
.
- > <: triggers when the channel's data word is greater than the upper limit
of the data word or smaller than the lower limit of the data word. Click or
tap the input field of Max and Min, and then the "Format" interface is
displayed. You can set the upper limit and lower limit of the data word. For
details, refer to descriptions in
I2C Trigger
.
• RTA: triggers on the specified remote terminal address. After this trigger
condition is selected, click or tap the input field of
RTA, and then the "Format"
interface is displayed. You can set the remote terminal address. For details, refer
to descriptions in
I2C Trigger
.
• RTA+11Bit: triggers on the RTA and the remaining 11 bits.
After this trigger condition is selected:
- Click or tap the input field of RTA, and then the "Format" interface is
displayed. You can set the remote terminal address. For details, refer to
descriptions in
I2C Trigger
.
- Click or tap the input field of
Bit Time, and then the "Format" interface is
displayed. You can set the bit time position value to 0 (low), 1 (high), or X
(don't care). For details, refer to descriptions in
I2C Trigger
.
• Error: triggers on the specified error type. After this trigger condition is selected,
click or tap the drop-down button of Err Type to select the error type.
- Sync Error: triggers when an invalid sync pulse is found.
- Check Error: triggers when the parity bit is incorrect for the data in the
word.
8.8 Zone Trigger
This series oscilloscope supports the zone trigger and provides two rectangle areas:
Trigger zone A and Trigger zone B. You can set the trigger conditions to "Intersect" or
"Not intersect". Refer to
Rectangle Drawing
to draw a rectangular in the waveform
view. When you move your finger away from the screen, the sub-menus are
displayed. Click or tap to select "Trigger zone A" or "Trigger zone B". Double-click the
area to enter the specified zone trigger interface. Also, in the Trigger menu, you can
click or tap
Trigger to enter the zone trigger interface.
Set the Trigger Zone
In the rectangular drawing mode, the region that you draw in the waveform view is
called the trigger zone. In the trigger zone interface, you can set "Center X" and
"Center Y" to adjust the position of the trigger zone. Set "Width" and "Height" to
adjust the area of the trigger zone.
To Trigger the Oscilloscope
MHO2000 User Guide
126
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
