Click or tap the input field of Level A and that of Level B to set Level A an Level B
with the pop-up numeric keypad. You can also use the trigger level knob or use the
specified multifunction knob to adjust Level A and Level B respectively. Check the
checkbox of Linkage to link Level A and Level B. The Level A and Level B will be
adjusted synchronously. The upper limit and lower limit values change at the same
time. The trigger level deviation (the difference between the upper limit and lower
limit of the trigger level) remains unchanged. For details, refer to descriptions in
Trigger Level
. The current trigger level is displayed in the trigger information label at
the top of the screen.
TIP
Press down the trigger level knob and rotate it to adjust Level A, Level B, and Level AB (when
linkage is enabled) in sequence.
Trigger Condition
Click or tap the drop-down button of When to set the the desired trigger condition.
• Sync: triggers on the specified sync type. After this trigger condition is selected,
click or tap the drop-down button of Sync to select the desired sync type: Data
Sync, Cmd/Status Sync, or All Sync.
• Data: triggers on the specified data word. After this trigger condition is selected,
click or tap the comparison conditions from the
Comp click. The available
choices include =, ≠, >, <, ><, and <>.
- =: triggers when the channel's data word equals the set data word. Click or
tap the input field of
Min, and then the "Format" interface is displayed. You
can set the lower limit of the data word. For details, refer to descriptions in
I2C Trigger
.
- ≠: triggers when the channel's data word does not equal the set data word.
Click or tap the input field of
Min, and then the "Format" interface is
displayed. You can set the lower limit of the data word. For details, refer to
descriptions in
I2C Trigger
.
- >: triggers when the channel's data word is greater than the set data word.
Click or tap the input field of Min, and then the "Format" interface is
displayed. You can set the lower limit of the data word. For details, refer to
descriptions in
I2C Trigger
.
- <: triggers when the channel's data word is smaller than the set data word.
Click or tap the input field of
Max, and then the "Format" interface is
displayed. You can set the upper limit of the data word. For details, refer to
descriptions in
I2C Trigger
.
- < >: triggers when the channel's data word is smaller than the upper limit
of the data word and greater than the lower limit of the data word. Click or
tap the input field of
Max and Min, and then the "Format" interface is
To Trigger the Oscilloscope
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
125
