Audio
Click or tap the drop-down button of Audio to select the audio channel ("Left",
"Right", or "Either").
Trigger Condition
Click or tap the drop-down button of When to set the the desired trigger condition.
• =: triggers when the channel's data equal the set data value. Click or tap the
input field of Data, and "Format" interface is displayed. You can set the data bit
that needs to be operated on.
• ≠: triggers when the channel's data do not equal the set data value. Click or tap
the input field of
Data, and then the "Format" interface is displayed. You can set
the data bit that needs to be operated on.
• >: triggers when the channel's data are greater than the set data value. Click or
tap the input field of Data Min, and then the "Format" interface is displayed. You
can set the lower limit of the data bit.
• <: triggers on when the channel's data are smaller than the set data value. Click
or tap the input field of
Data Max, and then the "Format" interface is displayed.
You can set the upper limit of the data bit.
• < >: triggers when the channel's data are smaller than the upper limit of the
data value and greater than the lower limit of the data value.. Click or tap the
input field of
Data Max and Data Min, and then the "Format" interface is
displayed. You can set the upper limit and lower limit of the data bit.
• > <: triggers when the channel's value is greater than the upper limit of the data
value and smaller than the lower limit of the data value. Click or tap the input
field of
Data Max and Data Min, and then the "Format" interface is displayed.
You can set the upper limit and lower limit of the data bit.
For details, refer to descriptions in
I2C Trigger
.
User Width
Click or tap the input field of User Width to set the user width with the pop-up
numeric keypad. You can also use the specified knob to set it. Its range is from 4 to
32.
The user width is smaller than or equal to the width.
Width
Click or tap the input field of
Width to set the width with the pop-up numeric keypad.
You can also use the specified knob to set it. Its range is from 4 to 32.
Alignment
Click or tap the drop-down button of
Alignment to select the alignment way for data
signal.
To Trigger the Oscilloscope
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO2000 User Guide
121
