• I2S: data transmission (MSB first) begins at the second edge of the WS
transition.
• LJ: data transmission (MSB first) begins at the edge of the WS transition.
• RJ: data transmission (MSB first) is right-justified to the WS transition.
Trigger Level
• SCLK Level: Click or tap the input field of SCLK Level to set the level of SCLK
with the pop-up numeric keypad. You can also use the specified multifunction
knob to set it.
• WS Level: Click or tap the input field of
WS Level to set the WS level with the
pop-up numeric keypad. You can also use the specified multifunction knob to set
it.
• SDA Level: Click or tap the input field of SDA Level to set the level of SDA with
the pop-up numeric keypad. You can also use the specified multifunction knob
to set it.
For details, refer to descriptions in
Trigger Level
. The current trigger level is displayed
in the trigger information label at the top of the screen.
8.7.20 MIL-STD-1553 Trigger (Option)
1553B is the abbreviation for the MIL-STD-1553 bus. This oscilloscope can trigger on
the sync field of 1553B bus, and can also trigger on the specified data word,
command word, status word, or error type.
The command word, data word, and status word format of the 1553B bus is as shown
in the figure below.
To Trigger the Oscilloscope
MHO2000 User Guide
122
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
