• With CS: if the CS signal is valid, the oscilloscope will trigger when the data
(SDA) satisfying the trigger conditions is found.
- Click or tap the drop-down button of CS to select the analog channel or the
digital channel as the CS channel. The current CS channel will be displayed
in the trigger information label at the top of the screen.
- Click or tap to select "Positive" (high level is valid) or "Negative" (low level is
valid) under
CS Mode.
• Timeout: the oscilloscope starts to search for the data (MISO) on which to
trigger after the clock signal (CLK) stays in the idle state for a specified period of
time. After selecting this condition, click or tap the input field of Timeout to set
the timeout value with the pop-up numeric keypad. You can also use the
specified knob to set it. The available range of the timeout value is from 8 ns to
10 s.
Data
Click or tap the input field of
Data, then the "Format" interface is displayed. You can
set the data bit that needs to be operated on. For details, refer to descriptions in
I2C
Trigger
.
Data Bits
Click or tap the input field of Data Bits to set the number of bits in the serial data
with the pop-up numeric keypad. You can also use the specified knob to set it. The
number of bits in the string can be set to any integer ranging from 4 to 32.
Level Selection and Setting
After the trigger condition setting is completed, you need to adjust the trigger level
to correctly trigger the signal and obtain a stable waveform.
• CLK Level: Click or tap the input field of
CLK Level to set the CLK level with the
pop-up numeric keypad. You can also use the specified multifunction knob to set
it.
• MISO Level: Click or tap the input field of
MISO Level to set the MISO level with
the pop-up numeric keypad. You can also use the specified multifunction knob
to set it.
• CS Level: Click or tap the input field of
CS Level to set the level of CS with the
pop-up numeric keypad. You can also use the specified multifunction knob to set
it.
For details, refer to descriptions in
Trigger Level
. The current trigger level is displayed
in the trigger information label at the top of the screen.
To Trigger the Oscilloscope
