M300 Quick Guide
30
data will be stored in the alarm queue (the data will be cleared at power-off). To
monitor a multiplexer channel, the DMM module must be installed and enabled
(Utility DMM “ON”); the channel to be monitored must be configured to
the scan list. You can monitor a DIO or TOT channel even if the channel is not
configured to the scan list.
2 Multi-channel Monitor
Press Monitor Multiple to enter the multi-channel monitor interface. At
most 7 channels can be monitored. You can add or delete the channels being
monitored.
3 All Channel Monitor
Press Monitor All Moni to enter the all-channel monitor interface. All the
channels in the scan list can be monitored.
Remote Control
M300 can communicate with PC through USB, LAN, GPIB and RS232 (converted from
the [RS-232/Alarms/Ext Trig] interface on the rear panel of M300) to realize
remote control based on the SCPI (Standard Commands for Programmable
Instruments) commands. This section introduces how to use the PC software Ultra
Sigma of RIGOL to control the instrument remotely through the USB interface. For
the detailed information about the SCPI commands, please refer to the Programming
Guide.
1 Install Ultra Sigma
Download Ultra Sigma from RIGOL website (www.rigol.com) and install it
according to the instructions.
2 Control the instrument via USB
(1) Connect the devices
Connect the USB Device interface of M300 to the USB Host interface of your
computer using a USB cable.
(2) Install the USB driver
As this instrument is a USB-TMC device, after you connect it to the PC and
turn both on for the first time, Found New Hardware Wizard is displayed on
the PC. Please install the “USB Test and Measurement Device (IVI)” driver
following the directions in the wizard.
(3) Search for device resources
Start up Ultra Sigma and the software will automatically search for the
instrument resources currently connected to the PC. You can also click
to search for the resources.
(4) View the device resource
The resources found will appear under the “RIGOL Online Resource”
