Contents RIGOL
M300 Quick Guide
29
channel.
Note: For channel copy, only copies between channels of the same type
(namely, channels of the same type of modules) are allowed.
3 Extended Copy:
Copy the configuration of a channel (source channel) of a module to all the
channels (of which the type is the same to that of the source channel) of the
target module.
Press Extended in the configuration copy interface to open the extended copy
interface.
(1) The “Source Channel” area is selected by default. Use the arrow keys to
select the desired source channel.
(2) Press Switch to move the cursor to the “Target Module” area and use the
up/down arrow key to select the desired target module.
(3) Press OK to execute extended copy.
Note: For extended copy, only copies among the same type of modules are
allowed. This function makes it easy to configure several channels with the same
configurations.
Channel Monitor
The channel monitor function of M300 allows users to monitor a single channel,
multiple channels or all of the channels in the scan list. The instrument monitors the
channel and takes readings from the channel monitored continuously even during a
scan. This function is helpful for troubleshooting your system before a test or for
observing important signals.
The channel monitor function can monitor the following channels: multiplexer
channels (configured to the scan list and the DMM module is enabled), DIO and TOT
channels of the multifunction module (no matter whether they are configured to the
scan list and the DMM module is not required). Press Monitor on the front panel to
configure the channel monitor function.
1 Single-channel Monitor
Press Monitor Single to enter the single-channel monitor interface. By
default, the first channel in the scan list is monitored. If no scan list is currently
configured, the first channel of the multifunction module (DIO channel) is
monitored. Only a single channel can be monitored at a time; but you can
change the channel being monitored at any time. Readings acquired during the
monitor process are displayed on the screen but will not be stored in memory.
When the alarm function is applied to the channel being monitored, all the alarm
