Contents RIGOL

M300 Quick Guide

27

configuration;

Select A, B and C and use the numeric keyboard to input the desired

scaling coefficients;

Select x1

and press Curr Value to acquire x1.

Select Unit and input the desired unit.

Note: For multiplexer channel using the “SENSOR” function and the DIO

and TOT channels of the multifunction module, the configuration guide

does not contain scaling configuration. Besides, for multiplexer channel, if

the DMM module is not currently inserted or it is inserted but is not enabled,

the configuration guide also does not contain “Scaling Configuration” when

an external DMM is connected to execute scan and measurement.

(3) Step 3: Alarm Configuration

Select Mode and use the left/right arrow key to select the desired alarm

mode (for example, HI);

Select Channel and use the left/right arrow key to select the desired alarm

channel (for example, Alarm1);

Select HI or LO and use the numeric keyboard to input the desired alarm

limit (for example, 12).

Note: For multiplexer channel, if the DMM module is not currently inserted

or it is inserted but is not enabled, the configuration guide does not contain

“Alarm Configuration” when an external DMM is connected to execute scan

and measurement.

(4) Step 4: Advanced Configuration

Select Integ and use the left/right arrow key to select the desired

integration time (for example 1PLC);

Select IMP and use the left/right arrow key to select 10MΩ or >10GΩ;

Select AZ and use the left/right arrow key to select “ON” or “OFF”;

Select Delay and use the left/right arrow key to “Auto” or set the delay time

manually.

Note: The parameters need to be set in this step depend on the

measurement function selected.

Press Done to finish the channel configuration guide and return to the scan

list editing interface.

4 Configure other channels to the scan list

Press New and configure other channels to the scan list according to step 3.

5 Save the scan list

After the scan list configuration is completed, you can press Save to save the

configured scan list in the internal or external memory of the instrument.
