M300 Quick Guide
28
Configuration Copy
M300 provides the configuration copy function (include module copy, channel copy
and extended copy) which can be used to quickly configure multi-channels with the
same configuration to the scan list.
Press Config Edit Copy to enter the configuration copy interface.
1 Module Copy:
Copy the configuration of a module (source module) to another module (target
module) of the same model. After that, the configuration of each channel of the
source module is copied to the target module automatically.
Press Module in the configuration copy interface to open the module copy
interface.
(1) The “Source Module” area is selected by default. Use the up/down arrow
key to select the desired source module.
(2) Press Switch to move the cursor to the “Target Module” area and use the
up/down arrow key to select the desired target module.
(3) Press OK to execute module copy.
Note: The source module and target module selected must be of the same
model. The configuration of a module to itself is not supported.
2 Channel Copy:
Copy the configuration of a channel (source channel) to another channel or
multiple channels (target channel) of the same type.
Press Channel in the configuration copy interface to open the channel copy
interface. By default, the channel selected is fixed as the source channel and the
upper area is selected. At this point, use the left/right arrow key to select the
desired target channel and press OK (pressing OK again will give up the
selection); press Done to execute channel copy.
After opening the channel copy interface, you also can press Switch to fix the
channel selected as the target channel. At this point, the lower area is selected.
Use the left/right arrow key to select the desired source channel and press
Done to execute channel copy.
Tips:
(1) When the channel selected is fixed as the source channel, multiple target
channels can be selected and will be displayed in the lower area.
(2) When the channel selected is fixed as the target channel, only a single
source channel can be selected.
(3) Switch is grayed out and disabled if the current scan list only has a single
