Contents RIGOL
M300 Quick Guide
21
Basic Operations
This section introduces the basic operations of M300, including how to connect the
signals to be measured, how to configure the scan list as well as how to control the
instrument remotely.
Measurement Connections
Multiple signals to be measured are connected to the plug-in modules through the
external terminal blocks and then are switched to the DMM module or external DMM.
M300 provides 9 kinds of terminal blocks. The models of the terminal blocks and
their corresponding modules are listed in the table below. This section introduces
how to connect the signals to be measured through the external blocks.
Note: For MC3724, there is no terminal block. You can connect your signals directly
to the on-board SMB connectors or to the SMB-to-BNC cables provided with the
module.
Table 1 External Terminal Blocks
Terminal Block
Module
1
M3TB20
MC3120
2
M3TB20A
MC3120A
3
M3TB32
MC3132
4
M3TB32T
MC3132
5
M3TB64
MC3164
6
M3TB24
MC3324
7
M3TB48
MC3648
8
M3TB16
MC3416
9
M3TB34
MC3534
WARNING
Cut off all the power supplies before opening the terminal block or
removing the terminal block from the module.
