RIGOL
M300 Quick Guide
20
Control
MC
3065
MC3164
MC
3120
MC
3120
A
MC3132
MC3324
DMM module, con not be controlled
Single-ended Multiplexer module:
(1) Disconnect the channel selected
(2) Close the channel selected
(3) Read the measurement value of the channel
selected
(4) Module reset
Multiplexer Module:
(1) Disconnect the channel selected
(2) Close the channel selected
(3) Read the measurement value of the channel
selected
(4) Module reset
(5) Bank Joined: used for 2-wire measurement
(6) Bank Separate: used for 4-wire measurement
MC3416
MC3648
Actuator/Matrix Switch:
(1) Disconnect the channel selected
(2) Close the channel selected
(3) Module reset
MC3534
Multifunction Module:
(1) DIO channel:
Read the input value of the channel selected;
Edit the output value of the channel selected
(2) TOT channel:
Read the count of the channel selected;
Start or stop counting
(3) DAC channel: edit the output value of the
channel selected
(4) Module reset
MC3724
Dual 4-Channel RF Multiplexer:
(1) Close the channel selected
(2) Module reset
Note: The disconnect operation is not supplied for this
module. To disconnect desired channel, you can close
one of the other channels in the same bank.
Alarm Channel Setting Keys
Alarm Channel Setting
(1) Set the output mode of the corresponding pin
when an alarm is generated to “Latch” or “Track”.
(2) Set the output status of the corresponding pin
when an alarm is generated to “High” or “Low”.
(3) Display the numbers of channels that select the
current alarm channel.
(4) Clear the alarm output of the corresponding pin.
The Alarm data is not cleared.
