Contents RIGOL
M300 Quick Guide
17
the User Guide or Data Sheet of this product.
9 MC3724 (Dual 4-Channel RF Multiplexer)
MC3724 provides two independent banks of 4-channel RF multiplexers and can
be used to switch high frequency pulse signals.
The channels in each bank have a common earth ground (the outer layer of
the SMB connectors is grounded).
Only one channel in each bank may be closed at a time.
You can connect your signals directly to the on-board SMB connectors (2
GHz bandwidth) or to the SMB-to-BNC cables (1 GHz bandwidth) provided
with the module.
You can cascade multiple RF multiplexers to create larger RF multiplexer.
To Use the Built-in Help System
The built-in help system of M300 provides the help information about any front panel
key and menu. To acquire the help information of any front panel key or menu, press
Help (the backlight goes on and “Help” is displayed in the status bar in the user
interface) and then press the desired key or menu. The built-in help interface is as
shown in the figure below. Pressing OK can exit the built-in help system.
Figure 8 Built-in Help System
Menu Quick Navigation
This section provides the structure diagrams of the main menus for M300 to guide
users to quickly get familiar with the operation methods of M300. For more detailed
information, please refer to the User’s Guide.
