Contents RIGOL
M300 Quick Guide
15
Module Overview
1 MC3065 (DMM Module):
The DMM module is used to measure the signals under test and provides 6½
digit reading resolution. Its measurement functions include DCV, ACV, DCI, ACI,
frequency, period, temperature and any sensor.
Note: After connecting the DMM module, make sure that the signal under test
connected to the analog bus is no greater than 300 Vdc or 300 Vrms.
2 MC3120 and MC3120A (20-Channel Multiplexer):
All the 20 channels switch both HI and LO inputs, thus providing fully isolated
signals for the DMM module. This module is divided into two banks (called A and
B) with 10 two-wire channels in each bank. All channels in the scan list are
break-before-make. You can close multiple channels on this module only if you
have not configured any channel to be part of the scan list.
This module can be connected with MC3065 (DMM Module, if MC3065 is
currently inserted).
For the specifications of this module, please refer to the User Guide or Data
Sheet of this product.
3 MC3132 (32-Channel Multiplexer):
All the 32 channels switch both HI and LO inputs, thus providing fully isolated
signals for the DMM module. MC3132 is divided into two banks (called A and B)
with 16 two-wire channels in each bank. All channels in the scan list are
break-before-make. You can close multiple channels on this module only if you
have not configured any channel to be part of the scan list.
This module can be connected with MC3065 (DMM Module, if MC3065 is
currently inserted).
For the specifications of this module, please refer to the User Guide or Data
Sheet of this product.
4 MC3164 (64-Channel Single-Ended Multiplexer):
All the 64 channels can only switch HI input. MC3164 is divided into two banks
(A and B) with 32 single-ended channels in each bank. All channels in the scan
list are break-before-make. In any case, you cannot close multiple channels on
this module.
This module can be connected with MC3065 (DMM Module, if MC3065 is
currently inserted).
For the specifications of this module, please refer to the User Guide or Data
Sheet of this product.
5 MC3324 (24-Channel Multiplexer):
All the 20 voltage channels switch both HI and LO inputs, thus providing fully
isolated inputs for the DMM module. The 20 voltage channels are divided into
two banks (called A and B) with 10 two-wire channels in each bank. All channels
