Contents RIGOL
M300 Quick Guide
13
Plug-in Module Overview
M300 provides 10 kinds of modules including the DMM module, 20-channel
multiplexer, 32-channel multiplexer, 64-channel multiplexer, multi-function module
and etc. This section introduces the functions and characteristics of each module.
Appearance Drawing
Figure 6 Appearance Drawing of the Plug-in Module
Golden Circuit board Edge: each on the
top and bottom for sliding into the slot
Interface 1: connect the signal under test via the
terminal block (MC3065 and MC3724 does not have
this interface)
Interface 2: connect
with the main frame
