M300 Quick Guide
12
User Interface
Figure 5 User Interface
1 Status Bar
Help
Displayed when the built-in help is enabled.
Error
Displayed when an error occurs.
Displayed when the keyboard is locked.
Displayed when an alarm is generated.
Displayed when the system sound is disabled.
Displayed when the instrument is connected to network correctly.
Displayed when an USB storage device is detected.
Local
Displayed when the instrument is in local mode.
Rmt
Displayed when the instrument is in remote mode.
2 Content Bar
Display the measurement configuration guide, measurement parameters
settings and etc. For more detailed information, please refer to the User’s Guide.
3 Menu Bar
Display the menus of the current function. The menus correspond to the menu
softkeys below respectively. Pressing the softkey can activate the corresponding
menu.
Status
Bar
Content
Bar
Menu
Bar
