MSP 405 User Manual
10
Ensure that all devices are in good condition with no damage or abnormalities.
2. Check the Power Adapter
Verify that the power adapter or battery meets the required voltage of 12V and current of no less
than 1.5A.
3. Configure HDMI Signal
Set your PC output resolution to 1920x1080P@60Hz. Connect the HDMI output port of PC to the
HDMI input port of HDMI monitor using an HDMI cable. Make sure the HDMI signal is displayed
correctly on the monitor.
4. Check SDI Signal and Cables
Connect the SDI output port of the SDI signal source (e.g., a camera) to the SDI input port of SDI
monitor using an SDI cable. Verify that the SDI signal is displayed on the monitor.
5. Check Grounding and Power Off
Confirm that the signal source and monitor are properly grounded, then disconnect all power
cables.
6. Select Mode
Set the MSP 405 to Mode 3 by using the DIP switch.
7. Connect HDMI Cable
Use an HDMI cable to connect the HDMI output port of the MSP 405 to the HDMI input port of
the HDMI monitor.
8. Connect SDI Cable
Use an SDI cable to connect the SDI output port of the SDI signal (e.g., a camera) to the SDI input
port of the MSP 405.
9. Connect Power
Connect the MSP 405, SDI signal source, and HDMI monitor to power and power them on.
10. Check SDI Input Signal
Check the SDI input signal via the MSP 405’s LCD screen. If the signal is not displayed, first check
if the MSP 405 is receiving adequate power, then verify the output of the SDI camera, and try
using a shorter cable to connect the MSP 405 and SDI camera if necessary.
11. Check HDMI Output Signal
