3 Design and function
Unit description
The local air conditioning unit is particularly well
suited to flexible use.
The local room air conditioner comprises a floor-
standing unit for the indoor area and an exhaust air
hose to conduct the heat away
. The indoor unit
extracts the heat from the room to be cooled by
means of an evaporator (heat exchanger) and
transfers it to the internal cooling cycle. This
releases the heat back to the outside via another
heat exchanger (condenser) by means of the flex-
ible exhaust air hose.
The condensate arising during cooling mode is
continually drained off via the condenser by means
of a condensate pump located in the unit - the con-
denser evaporates the condensate and discharges
it to the outside via the exhaust air hose.
The unit filters and dehumidifies the air thereby
creating a comfortable room climate. It works fully
automatically and offers numerous additional
options thanks to its microprocessor controller. The
operation of the unit can be conveniently operated
by means of the infra-red remote control included.
The USB port is only intended for use with the
REMKO WiFi stick. The function description can be
found in the operating instructions for the REMKO
WiFi stick.
2
1
4
A
3
Fig. 1: Front view
A: Air outlet, recirculation
1: Recessed grip
2: Control panel
3: Ventilation louvres
4: Transport castors
D
B
C
1
2
3
Fig. 2: Rear view
B: Air inlet, recirculation
C: Air inlet, exhaust air
D: Air outlet, exhaust air
1: Air filter, recirculation
2: Exhaust air hose connection
3: Condensate drainage with stopper
REMKO RKL Eco series
14
