2 Technical data
2.1 Unit data
Series RKL 355 Eco
Operating mode
Local compact air conditioning unit
for cooling
Nominal cooling output kW 3.5
Energy efficiency ratio - cooling A
Energy efficiency ratio EER 2.6
Energy consumption, cooling hourly kWh / 60 min 1.4
Application area room volume, approx.
m
3
110
Setting range °C +16 to +32
Operating range °C / %r.F. +16 to +35 / 35 to 85
Refrigerant R290
Refrigerant filling quantity kg 0.285
CO
2
equivalent
t 0
Operating pressure max. LP/HP/ HE
1)
MPa 1.2/2.4/2.6
Fan stages 3
Air flow volume per stage
m
3
/h
341/391/420
Dehumidification capacity l/h 3.3
Sound pressure level per speed setting dB(A) 49/50/51
Sound pressure level, Silent dB(A) 47.5
Sound power level, max. dB(A) 65
Power supply V/Ph/Hz 220-240/1~/50
Enclosure class IP X0
Electr. rated power consumption kW 1.35
Electr. rated current consumption A 5.75
Elec. current consumption, max. A 17
Exhaust air hose, length / diameter mm 1500/150
Dimensions - height/width/depth mm 714/414/345
Weight kg 32.0
1)
Low pressure/high pressure/heat exchanger
Information provided without guarantee! W
e reserve the right to make technical changes for the purpose of
technical advancement.
