INSTALLATION

Check the appliance is electrically safe and gas sound when you have nished.

Pressure Testing

The gas pressure can be measured at one of the hotplate

burner injectors (not the wok burner).

Lift o a burner head. Fit the pressure gauge to the injector.

Turn on and light one of the other hotplate burners.

Turn on the control knob for the burner with the pressure

gauge tted to let gas through.

See the data badge for test pressures.

Turn o the burners. Make sure that you reassemble the

burner top in the correct way on the burner body.

Electrical Connection

The cooker must be installed by a qualied electrician, in

accordance with all relevant British Standards/Codes of

Practice (in particular BS 7671), or with the relevant national

and local regulations.

n

WARNING: THIS APPLIANCE MUST BE EARTHED.

All external wiring must comply with the IEE Regulations

for the Electrical Equipment of Buildings. Connection to the

electrical supply can be made with either a plug and socket

or be permanently wired via a double-pole switch. The cooker

is supplied with a 3-core cable 2 m long. If a replacement

cable is tted it must be 250 V high temperature PVC (85 °C),

1 mm².

Should the plug not t the socket in your home, it should be

removed and replaced with a suitable plug.

Note: If the plug is tted is not suitable, it must be cut o and

disposed of properly. To avoid the risk of electrocution, the

plug must not be left where children might nd it and plug it

into a supply socket.

Three pin plugs to BS 1363 with a capacity of not less than

13 A must be used and tted with a 13 amp fuse ‘ASTA’

approved to BS 1362.

YOU MUST REFIT THE COVER AFTER REPLACING THE

FUSE. IF THE COVER IS lost, the plug must not be used until

a replacement cover has been obtained from your supplier.

The colour of the correct fuse carrier is that of the coloured

insert in the base of the fuse recess, or stated elsewhere

on the plug. Always state this colour when ordering a

replacement fuse carrier.

n

IMPORTANT: The wires in the mains lead are

coloured in accordance with the following code

(Fig. 10.14):

• Green and yellow: EARTH

• Blue: NEUTRAL

• Brown: LIVE

Earth: to the

terminal marked E,

coloured Green/Yellow

Live: to the

terminal marked L,

coloured Brown

Neutral: to the

terminal marked N,

coloured Blue

Fig. 10.14
