unDNEMO/unDNEMO-BT
User Manual
Attero Tech LLC 2020 Page 9 614-00032
2.3 – Bluetooth® Connectivity (unDNEMO-BT only)
2.3.1 – Pairing
The unDNEMO-BT can be paired with a Bluetooth® device for either wireless monitoring, or streaming audio from an enabled
device.
• Pairing Headphones/Headset monitor
o “Enable Menu Mode User Access” and “Enable Headphone/Headset support” MUST be selected in unIFY Control
Panel.
o Press “Menu” on the unDNEMO-BT, then “CH Up/Dwn” till Headset is selected. See Menu Mode Navigation section
for more details. “Scan” will be the automatically selected mode.
o Press “Select” to start scan. Make sure headphones/headset is in pairing mode. Once discovered,
headphone/headset device name will show on the unDNEMO-BT display.
o Press “Select to connect device.
• Pairing Bluetooth® audio equipped device
o “Enable Bluetooth Bridge” MUST be selected in unIFY Control Panel.
o Go do audio device Bluetooth® settings to start pairing. The unDNEMO is always in discoverable mode.
o Complete pairing per audio device settings.
Further information in the Bluetooth® menu options is available in the Menu Mode Navigation section 2.9.3 and 2.9.4.
2.3.2 – Wireless Headphone / Headset Monitoring
The unDNEMO-BT supports high quality wireless audio monitoring utilizing the Bluetooth® A2DP profile which is a high fidelity but
higher latency one way audio connection to headphones, headsets and speakers.
The unDNEMO-BT also supports lower latency, full duplex connectivity to headsets that support the HSP profile. When a compatible
headset is connected, the Bluetooth® microphone is added to the microphone prioritization.
The following priority is applied to the internal, external and Bluetooth® microphone sources. The highest priority source will mute
the low priority mics when present.
1. External wired microphone (highest priority)
2. Bluetooth® Microphone
3. Internal Microphone
When a headphone or headset is paired and connected to the unDNEMO-BT, the local volume controls on the unDNEMO-BT operate
the volume to the headphone/headset. However, the speaker mute button only mutes and unmutes the local speaker. This allows
normal operation of the unDNEMO-BT locally when the headphone/headset is located remotely allowing local monitoring.
Details of the connection management for the Bluetooth® setup can be found in the menu navigation section.
2.3.3 – Wireless Audio Bridging
In addition to wireless monitoring, the unDNEMO-BT allows users to stream their Bluetooth® audio equipped device to the
unDNEMO-BT for local monitoring or remote bridging to the Dante® network.
*Note: The Bluetooth® streaming functionality is not supported while also monitoring wirelessly with Bluetooth®. The user or
installer must select either the wireless monitoring or wireless streaming using the unIFY Control Panel software.
*Note: Once paired/connected, the Bluetooth® friendly name is visible to other devices. However, while another device may be able
to pair and save to its Bluetooth® device list when in this state, breaking the connection of the currently active device will not be
possible.
2.3.4 – Disable Bluetooth
Bluetooth can also be disabled by selecting “Disable Bluetooth” in the Bluetooth Setup section of unIFY Control Panel.
